Seal catalogue · Bulb Seals · Part

DU-069 copy

DU-069

W × H0.709 × 1.429 in MaterialRubber

Bulb Seals

Request a quote for DU-069 → Spec sheet (PDF) Print spec sheet

Cross-section drawing of DU-069 — Cross-section — DU-069Not to scale

Specification

As drawn.

Specification for DU-069
Width	0.709" 18.0 mm
Height	1.429" 36.3 mm
Flange	0.300" 7.6 mm
Material	Rubber
Type	Sponge
Durometer	2A3 (sponge grade)
Colour	Black
Mount	Push On
Bulb position	Top
Core	1.43in Wire
Second durometer	70 Durometer
Shape	Bulb Seal

Dimensions in inches to three places, as on the drawing; millimetres computed.

9 interchangeable parts

Substitutes from the catalogue.

Profiles that substitute for this one, from our own interchange records. Have a competitor's number? Search it in the seal catalogue for the closest equivalent.

DU-072 0.600 × 1.165 in · Rubber DU-116 0.660 × 1.250 in · Rubber SD-12122 0.600 × 1.400 in · Rubber SD-12155 0.787 × 1.296 in · Rubber SD-12672 0.680 × 1.670 in · Rubber SD-12676 0.600 × 1.130 in · Rubber SD-968 0.600 × 1.165 in · Rubber SD-968-200-Flange 0.600 × 1.165 in · Rubber SD-968-Tip 0.600 × 1.320 in · Rubber
