Seal catalogue · Bulb Seals · Part

DU-072 copy

DU-072

W × H0.600 × 1.165 in MaterialRubber

Bulb Seals

Request a quote for DU-072 → Spec sheet (PDF) Print spec sheet

Cross-section drawing of DU-072 — Cross-section — DU-072Not to scale

Specification

As drawn.

Specification for DU-072
Width	0.600" 15.2 mm
Height	1.165" 29.6 mm
Flange	0.190" 4.8 mm
Material	Rubber
Type	Sponge
Durometer	2A5 (sponge grade)
Colour	Black
Mount	Push On
Bulb position	Top
Second durometer	70 Durometer
Shape	Bulb Seal

Dimensions in inches to three places, as on the drawing; millimetres computed.

5 interchangeable parts

Substitutes from the catalogue.

Profiles that substitute for this one, from our own interchange records. Have a competitor's number? Search it in the seal catalogue for the closest equivalent.

DU-069 0.709 × 1.429 in · Rubber DU-116 0.660 × 1.250 in · Rubber SD-968 0.600 × 1.165 in · Rubber SD-968-200-Flange 0.600 × 1.165 in · Rubber SD-968-Tip 0.600 × 1.320 in · Rubber
