SD-110 Dense

W × H0.720 × 0.582 in MaterialPVC

Trim Seals

Request a quote for SD-110-Dense → Spec sheet (PDF) Print spec sheet

Cross-section drawing of SD-110-Dense — Cross-section — SD-110-DenseNot to scale

Specification

As drawn.

Specification for SD-110-Dense
Width	0.720" 18.3 mm
Height	0.582" 14.8 mm
Flange	0.185" 4.7 mm
Material	PVC
Second material	Rubber
Type	Dense
Durometer	70 Shore A
Colour	Black
Mount	Push On
Core	1in Stamped Steel

Dimensions in inches to three places, as on the drawing; millimetres computed.

4 interchangeable parts

Substitutes from the catalogue.

Profiles that substitute for this one, from our own interchange records. Have a competitor's number? Search it in the seal catalogue for the closest equivalent.

PTL-124 1.045 × 0.750 in · PVC SD-120-AA 0.950 × 0.550 in · PVC SD-1400-AL-1in-Bulb 1.330 × 1.000 in · PVC SD-1435-NAV-120-Bulb 1.070 × 0.765 in · PVC
