BD-1435

W × H0.350 × 0.660 in MaterialPVC

Edge Trims

Request a quote for BD-1435 → Spec sheet (PDF) Print spec sheet

Cross-section drawing of BD-1435 — Cross-section — BD-1435Not to scale

Specification

As drawn.

Specification for BD-1435
Width	0.350" 8.9 mm
Height	0.660" 16.8 mm
Flange	0.350" 8.9 mm
Material	PVC
Durometer	80 Shore A
Colour	Black
Texture	Leather Grain
Mount	Push On
Core	1.4in Stamped Steel

Dimensions in inches to three places, as on the drawing; millimetres computed.

7 interchangeable parts

Substitutes from the catalogue.

Profiles that substitute for this one, from our own interchange records. Have a competitor's number? Search it in the seal catalogue for the closest equivalent.

BD-1185 0.350 × 0.525 in · PVC BD-1550 0.710 × 0.620 in · PVC SD-1402 0.500 × 0.700 in · PVC SD-1430-BOYD 0.500 × 0.650 in · PVC SD-1450 0.671 × 0.580 in · PVC SD-1875 0.740 × 1.000 in · PVC SD-1875-W 0.740 × 1.000 in · PVC
