DU-004 copy

DU-004

W × H1.524 × 0.600 in MaterialRubber

Request a quote for DU-004 → Spec sheet (PDF) Print spec sheet

Cross-section drawing of DU-004 — Cross-section — DU-004Not to scale

Specification

As drawn.

Specification for DU-004
Width	1.524" 38.7 mm
Height	0.600" 15.2 mm
Flange	0.125" 3.2 mm
Material	Rubber
Type	Sponge
Durometer	2A2 (sponge grade)
Colour	Black
Mount	Push On
Core	SD-487 Spring Steel
Second durometer	70 Durometer
Shape	Flap Seal
Flap	1.090" 27.7 mm

Dimensions in inches to three places, as on the drawing; millimetres computed.

5 interchangeable parts

Substitutes from the catalogue.

Profiles that substitute for this one, from our own interchange records. Have a competitor's number? Search it in the seal catalogue for the closest equivalent.

FL-031 2.350 × 0.625 in · Rubber SD-360 1.242 × 0.637 in · Rubber SD-364 1.190 × 0.750 in · Rubber SD-498 2.141 × 0.650 in · Rubber SD-499 1.460 × 0.600 in · Rubber
