Seal catalogue · Slide-Out Seals · Part

TS-226 copy

TS-226

W × H1.250 × 0.275 in MaterialRubber

Slide-Out Seals

Request a quote for TS-226 → Spec sheet (PDF) Print spec sheet

Cross-section drawing of TS-226 — Cross-section — TS-226Not to scale

Specification

As drawn.

Specification for TS-226
Width	1.250" 31.8 mm
Height	0.275" 7.0 mm
Material	Rubber
Type	Dense
Durometer	70 Shore A
Colour	Black
Mount	Tape

Dimensions in inches to three places, as on the drawing; millimetres computed.
