Seal catalogue · Push On Rubber Seals · Part

SD-362 copy

SD-362

W × H1.345 × 0.650 in MaterialRubber
Push On Rubber Seals
Request a quote for SD-362 → Spec sheet (PDF) Print spec sheet
Cross-section drawing of SD-362
Cross-section — SD-362Not to scale
Specification

As drawn.

Specification for SD-362
Width 1.345" 34.2 mm
Height 0.650" 16.5 mm
Flange 0.125" 3.2 mm
Material Rubber
Type Sponge
Durometer 2A4 (sponge grade)
Colour Black
Mount Push On
Core SD-487 Spring Steel
Flap0.800" 20.3 mm

Dimensions in inches to three places, as on the drawing; millimetres computed.
