Seal catalogue · Tape Seals · Part

SD-338-DT copy

SD-338-DT

W × H3.000 × 1.125 in MaterialRubber

Tape Seals

Request a quote for SD-338-DT → Spec sheet (PDF) Print spec sheet

Cross-section drawing of SD-338-DT — Cross-section — SD-338-DTNot to scale

Specification

As drawn.

Specification for SD-338-DT
Width	3.000" 76.2 mm
Height	1.125" 28.6 mm
Material	Rubber
Type	Dense
Durometer	70 Shore A
Colour	Black
Mount	Tape
Tape	3M Heat-Activated Tape

Dimensions in inches to three places, as on the drawing; millimetres computed.
