Seal catalogue · Push On Rubber Seals · Part

SD-12628 copy

SD-12628

W × H1.472 × 0.984 in MaterialRubber
Push On Rubber Seals
Request a quote for SD-12628 → Spec sheet (PDF) Print spec sheet
Cross-section drawing of SD-12628
Cross-section — SD-12628Not to scale
Specification

As drawn.

Specification for SD-12628
Width 1.472" 37.4 mm
Height 0.984" 25.0 mm
Flange 0.230" 5.8 mm
Material Rubber
Type Dense
Durometer 70 Shore A
Colour Black
Mount Push On
Core 2in Wire
ShapeFlap Seal
Flap1.370" 34.8 mm

Dimensions in inches to three places, as on the drawing; millimetres computed.
