Seal catalogue · Other Extrusions · Part

RE-101 copy

RE-101

W × H0.709 × 0.669 in MaterialRubber

Other Extrusions Bulb Seals

Request a quote for RE-101 → Spec sheet (PDF) Print spec sheet

Cross-section drawing of RE-101 — Cross-section — RE-101Not to scale

Specification

As drawn.

Specification for RE-101
Width	0.709" 18.0 mm
Height	0.669" 17.0 mm
Material	Rubber
Type	Sponge
Durometer	2A5 (sponge grade)
Colour	Black
Bulb position	Top
Shape	Bulb Seal and D-Seal

Dimensions in inches to three places, as on the drawing; millimetres computed.
